VL102-Q4 QFN48
VL102R-Q4 QFN48
VL102 System Overview

微信/手机:13502838259
QQ:80193425
VL102-用于USB-C设备的DP Alt模式和PD 3.0控制器

VIA Lab’s VL102 is a highly integrated single chip DisplayPort Alternate mode and Power Delivery 3.0 controller for USB-C
devices that designed for applications like USB-C video adapters and USB-C multi-function docking stations. Integrated USB-C
charging UFP, VL102 can perform DP alt-mode video out functionality and simultaneously enable charging connected PD host
once external power is detected. Integrated USB-C DRP can either connect to USB-C power adapter to charge PD host or
connect to USB-C devices to do data transfer. A D+/D- charging ePHY is integrated to support chargers using D+/D- to do
protocol handshake. VL102’s Device Policy Manager could negotiate power rules between its DRP and UFP then enable power
charging-through. Charging a host under dead battery mode and fast role swap are supported. SBU1/SBU2 switch is built-in to
support USB-C cable flipping feature. USB Billboard device and USB-C bridge function are implemented to meet “VESA DP
Alt-Mode on USB Type-C” spec and let the USB host to communicate with PD products connected on downstream port. VL102-Q4 QFN48

Built-in required linear voltage regulators, Vbus voltage detector, and Vbus current detector, VL102 can work perfectly with
power input either from Vconn power or from Vbus power and can monitor abnormal power behavior. Up to 9 GPIO pins are
available for power discharge control, power switch control, data switch control, or other special application usage. The SPI
interface can support external flash for firmware upgrades through USB Billboard device. VL102 is available in QFN 48L
(6x6x0.85 mm) green packages to fit small form-factor design.VL102-Q4 QFN48

VL102-Q4 QFN48
VL102R-Q4 QFN48

主要特点
支持一个充电UFP和一个DRP的CC Logic＆PD Engine
VL102R-Q4 QFN48   符合USB C型电缆和连接器规范修订版1.2
VL102R-Q4 QFN48   符合USB供电规范3.0版1.0a
VL102R-Q4 QFN48   集成C型收发器，支持一个充电UFP和一个DFP DRP
VL102R-Q4 QFN48   内置上拉/下拉电阻，包括Rp，Rd和Ra
VL102R-Q4 QFN48   内置Vconn电源开关DP Alt模式配置
VL102R-Q4 QFN48   符合USB Type-C标准版本1.0a上的VESA DisplayPort Alt模式
VL102R-Q4 QFN48    DP模式发现/进入/退出
VL102R-Q4 QFN48    DP配置，状态更新，源/接收连接检测
VL102R-Q4 QFN48   内置Aux_CH开关USB-C充电UFP功能
VL102R-Q4 QFN48   一旦有外部电源可用，即可为连接的PD主机充电
VL102R-Q4 QFN48   支持提供商和消费者的角色
VL102R-Q4 QFN48   支持高达PD电源Profile 5作为电源
VL102R-Q4 QFN48   支持为死电池充电USB-C DRP功能
VL102R-Q4 QFN48   支持提供商和消费者角色
VL102R-Q4 QFN48   支持最高100W的接收器功率和15W作为源的PD功率规则
VL102R-Q4 QFN48   内置D + / D-为使用D + / D-作为协议握手的充电器为ePHY充电
VL102R-Q4 QFN48   内置USB HS数据开关USB广告牌设备和USB C桥
VL102R-Q4 QFN48   符合广告牌设备的USB设备类定义修订版1.1
VL102R-Q4 QFN48   符合USB Type-C桥接规范修订版1.0 RC
VL102R-Q4 QFN48   集成的内部USB2.0 PHY快速8051宏单元80C32兼容微控制器
VL102R-Q4 QFN48   标准1T 8051指令集
VL102R-Q4 QFN48   嵌入式Mask ROM和SRAM
VL102R-Q4 QFN48   支持外部SPI闪存以进行固件升级内置稳压器，电压检测器和电流检测器
VL102R-Q4 QFN48    5.0V至3.3V LDO和3.3V至1.8V LDO
VL102R-Q4 QFN48   在Vbus和Vconn之间自动选择电源
VL102R-Q4 QFN48    Vbus电压检测器和Vbus电流检测器用于电源监控用于特殊功能和控制的
GPIO VL102R-Q4 QFN48    9个用于应用程序定制的GPIO和一个I2C主接口物理
VL102R-Q4 QFN48    QFN 48绿色封装（6x6x0.85毫米）认证
VL102R-Q4 QFN48    PD 2.0认证TID：1010103应用
VL102R-Q4 QFN48    USB-C视频适配器
VL102R-Q4 QFN48    USB-C多功能扩展坞
